24V/1.7A 5V/0.5A Power Supply

Din Rail Mounted, 24V/5A Power Supply, 120W Input voltage : 85Vac to 264Vac Input current :

24V/1A power supply(no mounting) SPECIFICATIONS: Input Range : 100~250AC Input Frequency : 50Hz to 60 Hz Output : 24VDC/1Amp max. Output Power : 25 Watts Operating Temperature:0? to 70? C Storage Temperature : -40? to 85? C

24V/0.75A Power supply (No-Mounting) Input Range : 100~250AC Input Frequency : 50Hz to 60 Hz Output : 24VDC/0.6Amp max. Output Power : 15Watts Operating Temperature:0 to 70 C Storage Temperature : -40 to 85 C"

Din Rail Mounted, 24V/1.7A Power Supply, 40W Input voltage : 90VAC to 264VAC Input frequency : 47Hz to 63Hz Inrush current (Cold start) : less than 10A at 115VAC. less than 21A at 230VAC DC Outputs : +24V/1.7A Efficiency : higher than 70% at nominal line and rated load Holdup time : >20ms at rated load and 115VAC Over load protection : auto recovery Short circuit protection : auto recovery Over voltage protection : crowbar Operating temperature : 0 to 50 oC Cooling : Free air convection Storage temperature : -20 oC to +85 oC Dimension : 44 x 150 x125m

24 Volt / 2 Amp Panel Mount Power Supply ( Panel Mount) Input Range : 85V-26AC Input Frequency : 47Hz to 63 Hz Input Current : less than 1A at 115VAC or 0.6A at 230V Inrush Current : not exceed 30A at 115VAC or 60A at 230V Output : 24VDC/2A max. Ripple /Noise : Pk to Peak less than 240mV Line Regulation : less than +/-1% by changing the output load +/-40% from 60% rated lo Load Regulation : less than +/-1% by changing the output load +/-40% from 60% rated load Efficiency : higher than 7 Hold-up Time : 20ms (typ.) at 115V Protection: Over Voltage Protection . Trip point: 26.2V to 31V Operating Temperature : -20 to 70ºc Storage Temperature : -40 to 85ºc Altitude : 0-10,000 MTBF : 396,220 Hrs Power ON/OFF switch included Safe UL 1950 ,CSA 22.2 No. VDE EN 60 950 EMI : FCC docket 20780 curvB,EN55022 EMS : EN-50082 IEC 801-2,8KV (air discharge) criteria B IEC 801-3,3V/M criteria B IEC 801-4,2KV (air discharge) criteria B IEC 801-5,2KV (air discharge) criteria B Dimension : 198mm x 97mm x 40.5mm

24V/1A power supply ( DIN-Rail mount ) Input Range : 100~250AC Input Frequency : 50Hz to 60 Hz Output : 24VDC/1Amp max. Output Power : 25Watts Operating Temperature:0 to 70 C Storage Temperature : -40 to 85 C

24V/2A power supply (DIN-Rail mount) Input Range : 85V-26AC Input Frequency : 47Hz to 63 Hz Input Current : less than 1A at 115VAC or 0.6A at 230V Inrush Current : not exceed 30A at 115VAC or 60A at 230V Output : 24VDC/2A max. at ? C with free air cooling Ripple /Noise : Pk to Peak less than 240mV Line Regulation : less than +/-1% by changing the output load +/-40% from 60% rated lo Load Regulation : less than +/-1% by changing the output load +/-40% from 60% rated load Efficiency : higher than 7 Hold-up Time : 20ms (typ.) at 115V Protection : Over Voltage Protection . The trip point is around 26.2V to 31V output Volta Operating Temperature : -20? C to 70? C Storage Temperature : -40? C to 85? C Altitude : 0-10,000 MTBF : 396,220 Hrs Include power ON/OFF switch Safe UL 1950 ,CSA 22.2 No. VDE EN 60 950 EMI : FCC docket 20780 curv??B??,EN55022 EMS : EN-50082 IEC 801-2,8KV (air discharge) criteria B IEC 801-3,3V/M criteria B IEC 801-4,2KV (air discharge) criteria B IEC 801-5,2KV (air discharge) criteria B Dimension : 198mm x 97mm x 40.5mm"
