Ordinateurs Industriels | blocs d'alimentation pour ordinateur
ACE-540A
+24V 2A DC output power supply InputVoltage : 85 ~ 264V ACOutput-2A@24V DC, 50ºC with 20CFM air cooling-1.7A@24V DC, 50ºC with free air coolingLoad RegulationLess than +/-1% by changing the outputEfficiencyHigher than 70%Hold-up Time20ms (typical)@115V ACProtectionOver voltage protection.The trip point is around 26.2V ~ 31V outputOperating Temperature-20ºC ~ 70ºC(Will derate the output to 70% when operating at 70ºC)Storage Temperature-40ºC ~ 85ºCAltitude0 ~ 10,000ftMTBF396,220 Hours.SafetyUL 1950, CSA 22.2 No. 234, VDE EN 60950EMIFCC docket 20780 curve "B", EN55022EMS Standard- EN-50082-1- IEC 801-2 8KV (Air Discharge) criteria B- IEC 801-3, 3V/M criteria B- IEC 801-4, 2KV criteria B- IEC 801-5, 2KV criteria B
$83.00
ACE-716T
Rugged AT 150W -48V DC input power supply Intput TableACE-716A/AP: 85~135V or 180~265V AC' 47 to 440Hz, 4A@115V or 2A@230V ACACE-716C: +19 to +30V DC, 12A@+24V DCACE-716T: -36 to -72V DC, 6A@-48V DCOutput Table:ACE-716A/AP:Rated Load +5V:18A +12V:4A -5V:0.5A -12V:1AMax. Output +5V:25A +12V:10A -5V:1A -12V:1AACE-716C:Rated Load +5V:18A +12V:4A -5V:0.5A -12V:1AMax. Output +5V:25A +12V:10A -5V:1A -12V:1.5AACE-716T:Rated Load +5V:18A +12V:4A -5V:0.5A -12V:1AMax. Output +5V:25A +12V:10A -5V:1A -12V:1.5AInrush Current (ACE-716A/716AP)Not exceed 15A@115V AC or 30A@230V ACRipple and NoiseLess than 100mVLine RegulationThe line regulation for each outputs are less than +/-1%, while measuring at rated loading and +/-10% of input voltage changingLoad Regulation- ACE-716A/716AP : Less than +/-3%@+/-5V and -12V, +/-6%@+12V- ACE-716T/C : Less than +/-1%@+/-5V and -12V, +/-4%@+12VEfficiency- ACE-716A/716AP : Higher than 75%- ACE-716T/C : Higher than 70%Hold-up Time (ACE-716A/716AP)20ms (typical)@115V ACAltitude0 ~ 10,000ftProtectionOver voltage protection. The trip point is around 5.9V ~ 7.0V outputThermal ProtectionBuilt in 110ºC thermal switch in HS1Vibration10 ~ 55Hz at 2G 3min. period, 30 min. along X, Y and Z axisImpact10G for 20ms once on each X, Y and Z axisHi-pot isolation- 4300V DC, input to output for one minute- 2200V DC, input to ground for one minuteMTBF- ACE-716A : 188,800 hours- ACE-716T : 212,050 hours- ACE-716C : 187,490 hoursSafetyMeets UL 478, 1012, 1950; CSA 22.2 No. 234, VDE EN 60950EMI- Meets FCC docket 20780 curve "A", EN50081-2 : CISPR22 "A"- Harmonic EN 61000-3-2 for ACE-716APEMS Standard (Designed to meet the following limits)- EN 50082-2- IEC 801-1 8KV (Air Discharge) criteria B (ACE-716A/716AP)- IEC 801-3, 10V/M criteria A- IEC 801-4, 2KV criteria B (ACE-716A/716AP)- IEC 801-5, 2KV criteria B (ACE-716A/716AP)Built-in cooling fanOperating Temperature-20ºC ~ 70ºC(Derating curve will occur 50ºC ~ 70ºC)Storage Temperature-20ºC ~ 85ºCDimensions97(W) x 40.5(H) x 198(D)mm; (3.8" x 1.6" x 7.8")
$171.00
ACE-723A
Rugged AT 230W AC input auto-switch power supply Input Table:ACE723A/ACE723B:85~135V AC or 180~265V AC, 47~ 440Hz, 5A@115V AC or 3A@230ACACE723T:-36~-72V DC, 8A@48V DCACE723C:+19~+30V DC, 16A@+24V DCOutput Table(at 40ºC)ACE-723A:Rated Load: +5V:20A +12V:6A -5V:1A -12V:1AMax. Output: +5V:33A +12V:12A -5V:1.5A -12V:1.5AACE-723B:Rated Load: +5V:21A +12V:5A -12V:1A +24V:1AMax. Output: +5V:33A +12V:12A -12V:1.5A +24V:1.5AACE-723T:Rated Load: +5V:22A +12V:6A -5V:1A -12V:1AMax. Output: +5V:33A +12V:12A -5V:1.5A -12V:1.5AACE-723C:Rated Load: +5V:22A +12V:6A -5V:1A -12V:1AMax. Output: +5V:33A +12V:12A -5V:1.5A -12V:1.5AInrush Current (ACE-723A/B)Not exceed 15A@115V AC or 30A@230V ACRipple and NoiseLess than 100mVLine RegulationThe line regulation for each outputs are less than +/-1%, while measuring at rated loading and +/-10% of input voltage changingLoad RegulationLess than +/-1%@+/-5V and -12V, +/-4%@+12V and +24V (ACE-723B)EfficiencyHigher than 75%Hold-up Time (ACE-723A/B)20ms (typical)@115V ACProtectionOver voltage protection. The trip point is around 5.9V ~ 7.0V outputThermal ProtectionBuilt in 110+/-5ºC thermal switch in HS1Altitude0 ~ 10,000ftVibration10 ~ 55Hz at 2G 3min. period, 30 min. along X, Y and Z axisImpact10G for 20ms once on each X, Y and Z axisHi-pot isolation- 4300V DC, input to output for one minute- 2200V DC, input to ground for one minuteMTBF- ACE-723A : 206,500 Hours- ACE-723B : 206,300 Hours- ACE-723T : 206,700 Hours- ACE-723C : 205,900 HoursSafetyMeets UL 478, 1012, 1950; CSA 22.2 No. 234, VDE EN 60950EMIMeets FCC docket 20780 curve "A",EN50081-2 : CISPR22 "A"EMS Standard (Designed to meet the following limits)- EN 50082-2- IEC 801-1 8KV (Air Discharge) criteria B- IEC 801-3, 10V/M criteria A- IEC 801-4, 2KV criteria B- IEC 801-5, 2KV criteria BBuilt-in cooling fanOperating Temperature-20ºC ~ 70ºC(Derating curve will occur 50ºC ~ 70ºC)Storage Temperature-20ºC ~ 85ºCDimensions112(W) x 51(H) x 203(D)mm; (4.4" x 2" x 8")
$167.00
ACE-723B (Not available)
Rugged AT 230W AC input auto-switch power supply with +24V output (without -5V output) Input Table:ACE723A/ACE723B:85~135V AC or 180~265V AC, 47~ 440Hz, 5A@115V AC or 3A@230ACACE723T:-36~-72V DC, 8A@48V DCACE723C:+19~+30V DC, 16A@+24V DCOutput Table(at 40ºC)ACE-723A:Rated Load: +5V:20A +12V:6A -5V:1A -12V:1AMax. Output: +5V:33A +12V:12A -5V:1.5A -12V:1.5AACE-723B:Rated Load: +5V:21A +12V:5A -12V:1A +24V:1AMax. Output: +5V:33A +12V:12A -12V:1.5A +24V:1.5AACE-723T:Rated Load: +5V:22A +12V:6A -5V:1A -12V:1AMax. Output: +5V:33A +12V:12A -5V:1.5A -12V:1.5AACE-723C:Rated Load: +5V:22A +12V:6A -5V:1A -12V:1AMax. Output: +5V:33A +12V:12A -5V:1.5A -12V:1.5AInrush Current (ACE-723A/B)Not exceed 15A@115V AC or 30A@230V ACRipple and NoiseLess than 100mVLine RegulationThe line regulation for each outputs are less than +/-1%, while measuring at rated loading and +/-10% of input voltage changingLoad RegulationLess than +/-1%@+/-5V and -12V, +/-4%@+12V and +24V (ACE-723B)EfficiencyHigher than 75%Hold-up Time (ACE-723A/B)20ms (typical)@115V ACProtectionOver voltage protection. The trip point is around 5.9V ~ 7.0V outputThermal ProtectionBuilt in 110+/-5ºC thermal switch in HS1Altitude0 ~ 10,000ftVibration10 ~ 55Hz at 2G 3min. period, 30 min. along X, Y and Z axisImpact10G for 20ms once on each X, Y and Z axisHi-pot isolation- 4300V DC, input to output for one minute- 2200V DC, input to ground for one minuteMTBF- ACE-723A : 206,500 Hours- ACE-723B : 206,300 Hours- ACE-723T : 206,700 Hours- ACE-723C : 205,900 HoursSafetyMeets UL 478, 1012, 1950; CSA 22.2 No. 234, VDE EN 60950EMIMeets FCC docket 20780 curve "A",EN50081-2 : CISPR22 "A"EMS Standard (Designed to meet the following limits)- EN 50082-2- IEC 801-1 8KV (Air Discharge) criteria B- IEC 801-3, 10V/M criteria A- IEC 801-4, 2KV criteria B- IEC 801-5, 2KV criteria BBuilt-in cooling fanOperating Temperature-20ºC ~ 70ºC(Derating curve will occur 50ºC ~ 70ºC)Storage Temperature-20ºC ~ 85ºCDimensions112(W) x 51(H) x 203(D)mm; (4.4" x 2" x 8")
$184.00
ACE-723C (Not available)
Rugged AT 230W +24V DC input power supply Input Table:ACE723A/ACE723B:85~135V AC or 180~265V AC, 47~ 440Hz, 5A@115V AC or 3A@230ACACE723T:-36~-72V DC, 8A@48V DCACE723C:+19~+30V DC, 16A@+24V DCOutput Table(at 40ºC)ACE-723A:Rated Load: +5V:20A +12V:6A -5V:1A -12V:1AMax. Output: +5V:33A +12V:12A -5V:1.5A -12V:1.5AACE-723B:Rated Load: +5V:21A +12V:5A -12V:1A +24V:1AMax. Output: +5V:33A +12V:12A -12V:1.5A +24V:1.5AACE-723T:Rated Load: +5V:22A +12V:6A -5V:1A -12V:1AMax. Output: +5V:33A +12V:12A -5V:1.5A -12V:1.5AACE-723C:Rated Load: +5V:22A +12V:6A -5V:1A -12V:1AMax. Output: +5V:33A +12V:12A -5V:1.5A -12V:1.5AInrush Current (ACE-723A/B)Not exceed 15A@115V AC or 30A@230V ACRipple and NoiseLess than 100mVLine RegulationThe line regulation for each outputs are less than +/-1%, while measuring at rated loading and +/-10% of input voltage changingLoad RegulationLess than +/-1%@+/-5V and -12V, +/-4%@+12V and +24V (ACE-723B)EfficiencyHigher than 75%Hold-up Time (ACE-723A/B)20ms (typical)@115V ACProtectionOver voltage protection. The trip point is around 5.9V ~ 7.0V outputThermal ProtectionBuilt in 110+/-5ºC thermal switch in HS1Altitude0 ~ 10,000ftVibration10 ~ 55Hz at 2G 3min. period, 30 min. along X, Y and Z axisImpact10G for 20ms once on each X, Y and Z axisHi-pot isolation- 4300V DC, input to output for one minute- 2200V DC, input to ground for one minuteMTBF- ACE-723A : 206,500 Hours- ACE-723B : 206,300 Hours- ACE-723T : 206,700 Hours- ACE-723C : 205,900 HoursSafetyMeets UL 478, 1012, 1950; CSA 22.2 No. 234, VDE EN 60950EMIMeets FCC docket 20780 curve "A",EN50081-2 : CISPR22 "A"EMS Standard (Designed to meet the following limits)- EN 50082-2- IEC 801-1 8KV (Air Discharge) criteria B- IEC 801-3, 10V/M criteria A- IEC 801-4, 2KV criteria B- IEC 801-5, 2KV criteria BBuilt-in cooling fanOperating Temperature-20ºC ~ 70ºC(Derating curve will occur 50ºC ~ 70ºC)Storage Temperature-20ºC ~ 85ºCDimensions112(W) x 51(H) x 203(D)mm; (4.4" x 2" x 8")
$184.00
ACE-723T (Not available)
Rugged AT 230W -48V DC input power supply Input Table:ACE723A/ACE723B:85~135V AC or 180~265V AC, 47~ 440Hz, 5A@115V AC or 3A@230ACACE723T:-36~-72V DC, 8A@48V DCACE723C:+19~+30V DC, 16A@+24V DCOutput Table(at 40ºC)ACE-723A:Rated Load: +5V:20A +12V:6A -5V:1A -12V:1AMax. Output: +5V:33A +12V:12A -5V:1.5A -12V:1.5AACE-723B:Rated Load: +5V:21A +12V:5A -12V:1A +24V:1AMax. Output: +5V:33A +12V:12A -12V:1.5A +24V:1.5AACE-723T:Rated Load: +5V:22A +12V:6A -5V:1A -12V:1AMax. Output: +5V:33A +12V:12A -5V:1.5A -12V:1.5AACE-723C:Rated Load: +5V:22A +12V:6A -5V:1A -12V:1AMax. Output: +5V:33A +12V:12A -5V:1.5A -12V:1.5AInrush Current (ACE-723A/B)Not exceed 15A@115V AC or 30A@230V ACRipple and NoiseLess than 100mVLine RegulationThe line regulation for each outputs are less than +/-1%, while measuring at rated loading and +/-10% of input voltage changingLoad RegulationLess than +/-1%@+/-5V and -12V, +/-4%@+12V and +24V (ACE-723B)EfficiencyHigher than 75%Hold-up Time (ACE-723A/B)20ms (typical)@115V ACProtectionOver voltage protection. The trip point is around 5.9V ~ 7.0V outputThermal ProtectionBuilt in 110+/-5ºC thermal switch in HS1Altitude0 ~ 10,000ftVibration10 ~ 55Hz at 2G 3min. period, 30 min. along X, Y and Z axisImpact10G for 20ms once on each X, Y and Z axisHi-pot isolation- 4300V DC, input to output for one minute- 2200V DC, input to ground for one minuteMTBF- ACE-723A : 206,500 Hours- ACE-723B : 206,300 Hours- ACE-723T : 206,700 Hours- ACE-723C : 205,900 HoursSafetyMeets UL 478, 1012, 1950; CSA 22.2 No. 234, VDE EN 60950EMIMeets FCC docket 20780 curve "A",EN50081-2 : CISPR22 "A"EMS Standard (Designed to meet the following limits)- EN 50082-2- IEC 801-1 8KV (Air Discharge) criteria B- IEC 801-3, 10V/M criteria A- IEC 801-4, 2KV criteria B- IEC 801-5, 2KV criteria BBuilt-in cooling fanOperating Temperature-20ºC ~ 70ºC(Derating curve will occur 50ºC ~ 70ºC)Storage Temperature-20ºC ~ 85ºCDimensions112(W) x 51(H) x 203(D)mm; (4.4" x 2" x 8")
$184.00
ACE-815C (Discontinued )
100W 24VDC ATX Input Power Supply Input Range90V AC~264V AC full range (ACE-816AP/ACE-916AP)95V AC~132V AC, 180V AC~264V AC manual switch (ACE-816A/ACE-916A)ACE-816/916 Output RatingPIN1:+3.3V!O5%, Noise:50mvPIN2:+5V!O5%, Noise:50mvPIN3:+12V!O5%, Noise:120mvPIN4:-12V!O10%, Noise:120mvPIN5:+5Vsb!O5%, Noise:100mv[ACE-916A]Min:+5V 1.0A,+12V 0.2A,-12V 0AMax:+5V 15A,+12V 10A,-12V 0.3AThe output of +5V and +12V total output shall not exceed 146.4W, Total output maximum 150W[ACE-816A]Min:+3.3V 0.2A,+5V 1.0A,+12V 0.2A,-12V 0A,+5Vsb 0AMax:+3.3V 16A,+5V 15A,+12V 12A,-12V 0.3A,+5Vsb 2AThe output of +3.3V and +5V total output shall not exceed 61.5W, The +3.3V and +5V, +12V total output shall not exceed 136.4W, Total output maximum 150W[ACE-916AP]Min:+5V 1.0A,+12V 0.5A,-12V 0AMax:+5V 16A,+12V 6A,-12V 0.3AThe output of +12V and +5V total output shall not exceed 145W, Total output maximum 150W[ACE816AP]Min:+3.3V 0.3A,+5V 1.0A,+12V 0.3A,-12V 0A,+5Vsb 0AMax:+3.3V 10A,+5V 14A,+12V 4.2A,-12V 0.3A,+5Vsb 2AThe output of +3.3V and +5V total output shall not exceed 85W, Total output maximum 150WACE-815T Output RatingPIN1:+3.3V!O5%, Noise:50mv, Min:0.0A, Max:10.0APIN2:+5V!O5%, Noise:50mv, Min:0.0A, Max:14.0APIN3:+12V!O5%, Noise:120mv, Min:0.0A, Max:4.2APIN4:-5V!O5%, Noise:100mv, Min:0.0A, Max:0.3APIN5:-12V!O10%, Noise:120mv, Min:0.0A, Max:0.3APIN6:+5Vsb!O5%, Noise:100mv, Min:0.0A, Max:2.0A(+5V, +3.3V and +12V total output not exceed 135W)ACE-815C Output RatingPIN1:+3.3V!O5%, Noise:50mv, Min:0.0A, Max:4.0APIN2:+5V!O5%, Noise:50mv, Min:0.0A, Max:13.0APIN3:+12V!O5%, Noise:120mv, Min:0.0A, Max:2.5APIN5:-12V!O10%, Noise:120mv, Min:0.0A, Max:0.3APIN6:+5Vsb!O5%, Noise:100mv, Min:0.0A, Max:2.0A(+5V, +3.3V and +12V total output not exceed 84W)Hold-up time :17ms min. (AC Input Power Supply only)Efficiency :68% typ. (ACE-816AP/916AP); 72% typ. (ACE-816A/916A)Protection :Over Voltage/Load Protection and Short Circuit ProtectionTTL signal compatible power good signalVibration :10-55Hz at 2G 3min. period, 30 min. along X, Y and Z axis.Shock :10G for 11ms once on each X, Y and Z axis.Built-in cooling fanPower Connector:ATX (ACE-816A/AP/815T/815C) ; P8/P9 (ACE-916A/AP)MTBF :100,000hrs at 25ºCSafety :Meets UL 1950, CSA 22.2 Level 3,TUV, CCC.EMI :Meets FCC class "B",EN55022 class "B" Meets Harmonic EN61000-3-2 (ACE-815AP, ACE-915AP)EMS Standard :meet- IEC 801-2 8KV(Air Discharge)- IEC 801-3 3V/M criteria A- IEC 801-4,2KV criteria B- IEC 801-5,2KV criteria BOperating Temp. : 0-50ºC
Appelez-nous
ACE-816A (Discontinued) See ACE-A615A-RS
150W ATX Power Supply Input Range90V AC~264V AC full range (ACE-816AP/ACE-916AP)95V AC~132V AC, 180V AC~264V AC manual switch (ACE-816A/ACE-916A)ACE-816/916 Output RatingPIN1:+3.3V!O5%, Noise:50mvPIN2:+5V!O5%, Noise:50mvPIN3:+12V!O5%, Noise:120mvPIN4:-12V!O10%, Noise:120mvPIN5:+5Vsb!O5%, Noise:100mv[ACE-916A]Min:+5V 1.0A,+12V 0.2A,-12V 0AMax:+5V 15A,+12V 10A,-12V 0.3AThe output of +5V and +12V total output shall not exceed 146.4W, Total output maximum 150W[ACE-816A]Min:+3.3V 0.2A,+5V 1.0A,+12V 0.2A,-12V 0A,+5Vsb 0AMax:+3.3V 16A,+5V 15A,+12V 12A,-12V 0.3A,+5Vsb 2AThe output of +3.3V and +5V total output shall not exceed 61.5W, The +3.3V and +5V, +12V total output shall not exceed 136.4W, Total output maximum 150W[ACE-916AP]Min:+5V 1.0A,+12V 0.5A,-12V 0AMax:+5V 16A,+12V 6A,-12V 0.3AThe output of +12V and +5V total output shall not exceed 145W, Total output maximum 150W[ACE816AP]Min:+3.3V 0.3A,+5V 1.0A,+12V 0.3A,-12V 0A,+5Vsb 0AMax:+3.3V 10A,+5V 14A,+12V 4.2A,-12V 0.3A,+5Vsb 2AThe output of +3.3V and +5V total output shall not exceed 85W, Total output maximum 150WACE-815T Output RatingPIN1:+3.3V!O5%, Noise:50mv, Min:0.0A, Max:10.0APIN2:+5V!O5%, Noise:50mv, Min:0.0A, Max:14.0APIN3:+12V!O5%, Noise:120mv, Min:0.0A, Max:4.2APIN4:-5V!O5%, Noise:100mv, Min:0.0A, Max:0.3APIN5:-12V!O10%, Noise:120mv, Min:0.0A, Max:0.3APIN6:+5Vsb!O5%, Noise:100mv, Min:0.0A, Max:2.0A(+5V, +3.3V and +12V total output not exceed 135W)ACE-815C Output RatingPIN1:+3.3V!O5%, Noise:50mv, Min:0.0A, Max:4.0APIN2:+5V!O5%, Noise:50mv, Min:0.0A, Max:13.0APIN3:+12V!O5%, Noise:120mv, Min:0.0A, Max:2.5APIN5:-12V!O10%, Noise:120mv, Min:0.0A, Max:0.3APIN6:+5Vsb!O5%, Noise:100mv, Min:0.0A, Max:2.0A(+5V, +3.3V and +12V total output not exceed 84W)Hold-up time :17ms min. (AC Input Power Supply only)Efficiency :68% typ. (ACE-816AP/916AP); 72% typ. (ACE-816A/916A)Protection :Over Voltage/Load Protection and Short Circuit ProtectionTTL signal compatible power good signalVibration :10-55Hz at 2G 3min. period, 30 min. along X, Y and Z axis.Shock :10G for 11ms once on each X, Y and Z axis.Built-in cooling fanPower Connector:ATX (ACE-816A/AP/815T/815C) ; P8/P9 (ACE-916A/AP)MTBF :100,000hrs at 25ºCSafety :Meets UL 1950, CSA 22.2 Level 3,TUV, CCC.EMI :Meets FCC class "B",EN55022 class "B" Meets Harmonic EN61000-3-2 (ACE-815AP, ACE-915AP)EMS Standard :meet- IEC 801-2 8KV(Air Discharge)- IEC 801-3 3V/M criteria A- IEC 801-4,2KV criteria B- IEC 801-5,2KV criteria BOperating Temp. : 0-50ºC
Appelez-nous
