I-8058

FEATURES: 16-channel Isolated Digital Input Module SPECIFICATIONS: Digital Input Channels: 8 LED indicator for each channel of D/I Input type: differential Power Consumption: 0.8W Input Voltage Logical High: AC/DC 80V mini Logical Low: AC/DC 30V max. Maximum Input voltage: AC/DC 250 V Operating frequency: 1KHz (Max.) Isolation Voltage: 3750 Vrms

$213.00

I-8058G

FEATURES: 16-channel Isolated Digital Input Module SPECIFICATIONS: Digital Input Channels: 8 LED indicator for each channel of D/I Input type: differential Power Consumption: 0.8W Input Voltage Logical High: AC/DC 80V mini Logical Low: AC/DC 30V max. Maximum Input voltage: AC/DC 250 V Operating frequency: 1KHz (Max.) Isolation Voltage: 3750 Vrms

$215.00

I-8060

FEATURES: 6-channel Relay Output Module SPECIFICATIONS: Parallel I/O Module Relay on time: 3 ms Digital Output Channels:6 Relay off time: 1 ms Form C x 6 channels Total switch time: 10ms Contact Rating AC: 125V @0.6A; 250V @0.3A DC: 30V @2A; Insulation resistance: 1000M£[ min. at 500Vdc LED indicator for each digital output Power consumption: 2.2W Breakdown voltage: 500Vac

$295.00

I-8060G

FEATURES: 6-channel Relay Output Module SPECIFICATIONS: Parallel I/O Module Relay on time: 3 ms Digital Output Channels:6 Relay off time: 1 ms Form C x 6 channels Total switch time: 10ms Contact Rating AC: 125V @0.6A; 250V @0.3A DC: 30V @2A; Insulation resistance: 1000M£[ min. at 500Vdc LED indicator for each digital output Power consumption: 2.2W Breakdown voltage: 500Vac

$289.00

I-8063

FEATURES: 8-channel Isolated Digital I/O Module SPECIFICATIONS: Parallel I/O Module Digital input channels : 4 Differential input Digital output channels : 4 Form C relay AC : 125V@0.6A;250V@0.3A Power Consumption: 2.0W

$262.00

I-8063G

FEATURES: 8-channel Isolated Digital I/O Module SPECIFICATIONS: Parallel I/O Module Digital input channels : 4 Differential input Digital output channels : 4 Form C relay AC : 125V@0.6A;250V@0.3A Power Consumption: 2.0W

$260.00

I-8064

FEATURES: 8-channel Power Relay Output Module SPECIFICATIONS: Serial I/O Module Digital Output Channels: 8 Form A x 8 channels Contact Rating AC: 250V @ 5A DC: 30V @ 5A Insulation resistance: 1000MW min at 500Vdc LED indicator for each digital output 7000 command compatible Supports dual watchdog function Supports power-up value for each digital output Supports safe value for each digital output Power Consumption: 0.8W

$287.00

I-8064G

8-channel Power Relay Output Module Serial I/O Module Digital Output Channels: 8 Form A x 8 channels Contact Rating AC: 250V @ 5A DC: 30V @ 5A Insulation resistance: 1000MW min at 500Vdc LED indicator for each digital output 7000 command compatible Supports dual watchdog function Supports power-up value for each digital output Supports safe value for each digital output Power Consumption: 0.8W

$276.00
