32-Channel Single-Ended Isolated Analog Input Board PISO-813 with daughter board DB-8325 FEATURES: PCI Bus 32 single-ended analog input channels 12-bit A/D converter ( ADS 774 or equivalent) 3,000Vdc photo-isolation protection v Analog input range Bipolar: +/-10V,+/-5 V, +/-2.5V, +/-1.25V, +/-0.625V Unipolar: 0-10V, 0-5V, 0-2.5V, 0-1.25V Programmable gain control 3000V DC/DC converter built-in A/D trigger mode: Software Trigger A/D data transfer mode : polling SPECIFICATIONS: Channels : 32 single-ended Resolution : 12-bit Conversion rate : 10KS/s max. Input impedance : 10 M Ohm Overvoltage protection : +/-35V Accuracy : 0.01% of reading +/- 1-bit Linearity : +/- 1-bit On chip sample & hold Zero drift : +/-25ppm/oC of FS max. Power Requirements: +5V @850mA max. Environmental Operating temp 0-50?C Storage temp -20 to 70?C Humility 0 to 90% non-condensing Dimensions 180 mm x 105 mm

16 isolated digital input and 16 isolated digital output FEATURES: 16-channel optically isolated digital input 16-chanel Optically isolated open-collector output 16-channel TTL level digital input (Non-isolation) 16-channel TTL level digital output (Non-isolation) DC/DC converter build-in One 37-pin D-sub connector and Two sparate 20-pin header for isolated I/O Two 20-pin header for TTL digital I/O (Non-isolatiton) 2500Vdc isolation voltage Interrupt handling Interrupt source : channel 0 and channel 16 SPECIFICATIONS Isolated Digital I/O Isolated Input Channels : 16 Type : Isolated Current input Isolation Voltage : 2500V Input Voltage : 3.5V to 30V Input impedance : 1.2K ohm Response time : 10Khz Max Isolated Open-collector Output Channels : 16 Output voltage : Open-collector 5 to 40vdc Isolation voltage: 2,500Vdc Sink current: 200mA (Max.) Response time : 10Khz max. Non-Isolated Digital I/O Digital Input Channel : 16 Type : TTL Level Input Voltage : High : 2.0(min.) / Low :0.8 V(max.) Input Load : High : 50mA max. @2.7V; Low: 40mA / max.@0.5V Response Time : 30Khz max. Digital Output Channel : 16 Type: TTL Level High : Source 0.4mA at 2.4V mon. Low : sink 8 mA at 0.5V max. Interrupt Sorce : Isolated Digital input channel 0 and 1 Non- isolated digital input channel 0 and 1 General Environment Operating temp : 0~50 ?C Storage temp : -20 ~70 ?C Humidity : 0~90% non-condensing Dimensions : 172 mm x 124mm"

64-channel Optically Isolated open-collector Digital Output Board FEATURES: 32-channel optically isolated digital output / Open-collector Four isolated bank 3750Vdc isolation voltage" SPECIFICATIONS: Open-collector Output Type : Isolated open-collector : 100mA per channel External voltage : 30Vdc(max.) Response time : 1Khz (typical) Power requirement Power consumption : +5Vdc @800mA (max.) General Environment Operating temp : 0~50ºC Storage temp : -20 ~70ºC Humidity : 0~90% non-condensing Dimensions : 163 mm x 115mm

64 isolated digital input FEATURES: 64-channel optically isolated digital input DC/DC converter build-in Four isolated bank 3000Vdc isolation voltage Interrupt handling Interrupt source : channel 0 and channel 16 SPECIFICATIONS: Isolated Input Type : Isolated Current input Isolation Voltage : 3750V (Using External Power) , 3000V (Using Internal Power) Input Voltage : 3.5V to 30V Input impedance : 3K ohm Input Current : DC24V @ 7.67mA / Each channel Response time : 10Khz Max Power requirement Power consumption : +5Vdc @400mA (max.) General Environment Operating temp : 0~50º C Storage temp : -20 ~70º C Humidity : 0~90% non-condensing Dimensions : 163 mm x 115mm"

32 isolated digital input and 32 isolated open collector output FEATURES: 32-channel optically isolated digital input 32-channel optically isolated digital output / Open-collector DC/DC converter build-i Four isolated bank 3000Vdc isolation voltage Interrupt handling Interrupt source : channel 0 and channel 16" SPECIFICATIONS: Isolated Input Type : Isolated Current input Isolation Voltage : 3750V (Using External Power) , 3000V (Using Internal Power) Input Voltage : 3.5V to 30V Input impedance : 3K ohm Input Current : DC24V @ 7.67mA / Each channel Response time : 10Khz Max Open-collector Output Type : Isolated open-collector : 100mA per channel External voltage : 30Vdc(max.) Power requirement Power consumption : +5Vdc @600mA (max.) General Environment Operating temp : 0~50ºc Storage temp : -20 ~70ºc Humidity : 0~90% non-condensing Dimensions : 163 mm x 115mm

Isolated 16 Digital Input & 16 Relay Output Board FEATURES: Relay Output Channel optically isolated digital input channels AC/DC signal Input AC signal input with filter Connector pin assignment is compatible to 725 series Power Requirements : +5V 200mA(max.) ; +12V 260 mA (max.) SPECIFICATIONS: Relays Relay output Channel: 16 Contact Rating 0.3 A ;120V AC/DC / 1A ; 30V DC Contact arrangement Output channel 0-3 are Form C Output channel 4-7 are Form A Operating time 5 m Sec Release time 10m Sec Expected life > 100,000 times (Electrical at 30V/1A) Inputs Channels: 16 Type Non-polarized OPTO-isolated , (PC-814) Input Voltage AC/DC 5-24V ( Vac Feq:50~1Khz) Input Impedance 1.2 KW Response Time 20mS ( Without filter)22mS ( With filter) Isolation 500V channel-channel & channel-ground General Environment Operating temp 0-50?c Storage temp -20 to 70?c Humidity 0 to 90% non-condensing Dimensions 175 cm x 121 cm

Isolated 8 Digital Input & 8 Relay Output Board FEATURES: Relay output Channel Optically isolated digital input channels AC/DC signal Input ; AC signal input with filter Connector pin assignment is compatible to 725 series Power Requirements : +5V 200mA(max.) ; +12V 260 mA (max.) SPECIFICATIONS: Relays Relay output Channel 8 Contact Rating 0.3 A ;120V AC/DC / 1A ; 30V DC Contact arrangement Output channel 0-3 are Form C Output channel 4-7 are Form A Operating time 5 m Sec Release time 10m Sec Expected life > 100,000 times (Electrical at 30V/1A) Inputs Channels 8 Type Non-polarized OPTO-isolated , (PC-814) Input Voltage AC/DC 5-24V ( Vac Feq:50~1Khz) Input Impedance 1.2 KW Response Time 20mS ( Without filter)22mS ( With filter) Isolation 500V channel-channel & channel-ground General Environment Operating temp 0-50 degºc Storage temp -20 to 70ºc Humidity 0 to 90% non-condensing Dimensions 175 cm x 121 cm

14 bit 8 Channel Isolated Analog Output Board ISO-DA8 with DN-37 FEATURES: AT bus 500VDC photo-isolation protection 8/16 channel, 12-bit analog output Build in FIFO for continuous throughput Maximum 100KHz , 12 bit voltage output Unipolar or bipolar outputs available from each converter Voltage/ current outputs from each converter Output Type ( Unipolar or Bipolar ) and output range ( 0~5v,+/- 5V,0~10V,+/- 10V) can be jumper selectable 4-20mA current sink to ground from each converter On board reference of -10 V or -5V ( jumper selectable) Double-buffered D/A latches with simultaneous update for each 4 channel group (channels: 0-3,4-7,8-11,12-15) Command set programming Software Calibration SPECIFICATIONS: Voltage Output Range Unipolar 0~5V or 0~10V Bipolar +/-10Vor,+/- 5V Current drive +/-5mA Absolute accuracy 0.01% FSR typical Power on state 0V bipolar ; 5V unipolar Current Output Range Current output 0-20mA or 4-20mA Absolute Accuracy 0.1% FSR typical Excitation voltage range + 7 V to +40V Power On state 4mA bipolar , 12mA Unipolar Stability Offset temperature coefficient +/- 50mV/ deg C Gain temperature coefficient +/- 10ppm (C) General Environmental Power Requirements: ISO-DA8 +5VDC @800mA max. ISO-DA16+5VDC @1400mA max. Operating temp 0-50 deg/ C Storage temp -20 to 70 deg/C Humidity 0 to 90% non-condensing Dimensions 182 mm x 122 mm"
