4U 14-slot ATX MB rackmount White chassis with ACE-828A power supply 4U height 19" Rack mounting chassisFront panel with lockable door to protect the running systemAT type KBD connector on front panelDrive Bays :1x 3.5" FDD,2x3.5" internal and 2 x 5.25" DriveOne 12cm cooling fan with removable filterDesigned with an anti-vibration card clamp that keep the system stableSupports power supply: PS/2 size ATX PSUVibration:5 ~ 17Hz, 0.1" double amplitude displacement 17 ~ 640Hz, 1.5G acceleration peak to peakShock: 10G acceleration peak to peak (11ms)Color: White (PANTONE 413C)Dimensions: 431(W) x 177(H) x 450(D)mm; (17" x 7" x 17.7")Net/GW (kg): 15/17

4U ATX MB rackmount Black chassis with ACE-828A power supply 4U height 19" Rack mounting chassisFront panel with lockable door to protect the running systemBracket area is located in the front for easy accessto the cablesOne USB port on front panelDrive Bays:RACK-814: - 1 x 3.5" FDD, 1 x 5.25" Drive, 1 x 3.5"HDDThree hot-removable 8cm cooling fansDesigned with anti-vibration card clamp to keepingsystem stableSupports ATX form factor PC motherboard(RACK-814)Supports power supply: PS/2 size ATX PSUOptional rack-mount slide: 24" or 18"Vibration:5~17Hz, 0.1" double amplitude displacement17~640Hz, 1.5G acceleration peak to peakShock: 10G acceleration peak to peak (11ms)Colors:Black (PANTONE Black C) or White (PANTONE 413C)Dimensions:431(W) x 176(H) x 465.4(D)mm; (17" x 6.9" x 18.3")Net/GW (kg): 13/18

4U ATX MB rackmount White chassis with ACE-828A power supply 4U height 19" Rack mounting chassisFront panel with lockable door to protect the running systemBracket area is located in the front for easy accessto the cablesOne USB port on front panelDrive Bays:RACK-814: - 1 x 3.5" FDD, 1 x 5.25" Drive, 1 x 3.5"HDDThree hot-removable 8cm cooling fansDesigned with anti-vibration card clamp to keepingsystem stableSupports ATX form factor PC motherboard(RACK-814)Supports power supply: PS/2 size ATX PSUOptional rack-mount slide: 24" or 18"Vibration:5~17Hz, 0.1" double amplitude displacement17~640Hz, 1.5G acceleration peak to peakShock: 10G acceleration peak to peak (11ms)Colors:Black (PANTONE Black C) or White (PANTONE 413C)Dimensions:431(W) x 176(H) x 465.4(D)mm; (17" x 6.9" x 18.3")Net/GW (kg): 13/18

4U 14-slot rackmount Green chassis with ACE-C232 redundant power supply 4U height 19" Rack mounting chassisPlastic front panel with lockable door to protect the running systemTwo reset switches for dual system applicationsAT type KBD connector on front panel with cap protectionDrive Bays:-2 x 3.5" FDD - 2 x 5.25" DriveOne 12cm cooling fan with removable filterDesigned with anti-vibration card clamp to keep system stableSupports AT/ATX form factor PC motherboardSupports backplane: BP-14S, BP-14SD, PCI-14S, PCI-14S2, PCI-13SD, PX-14S5, PX-14S2, IP-14S; PCI-8S or BP-8S, PCIAGP-7S, PXAGP-7S, (For RACK-300AxM version)PCIAGP-13S2, PCIAGP-13S3, PXAGP-12S2, PXAGP-13S, PXAGP-13S3Supports power supply:PS/2 size AT/ATX PSUOptional Sliding Rails Kit:24" or 18"Vibration:5 ~ 17Hz, 0.1" double amplitude displacement17 ~ 640Hz, 1.5G acceleration peak to peakShock:10G acceleration peak to peak (11ms)Colors:Industrial Green (PANTONE 417C) or White (PANTONE 413C)Dimensions:431(W) x 176(H) x 433(D)mm; (17" x 6.9" x 17") Net/GW (kg):11/14

4U 14-slot rackmount White chassis with ACE-C232 redundant power supply 4U height 19" Rack mounting chassisPlastic front panel with lockable door to protect the running systemTwo reset switches for dual system applicationsAT type KBD connector on front panel with cap protectionDrive Bays:-2 x 3.5" FDD - 2 x 5.25" DriveOne 12cm cooling fan with removable filterDesigned with anti-vibration card clamp to keep system stableSupports AT/ATX form factor PC motherboardSupports backplane: BP-14S, BP-14SD, PCI-14S, PCI-14S2, PCI-13SD, PX-14S5, PX-14S2, IP-14S; PCI-8S or BP-8S, PCIAGP-7S, PXAGP-7S, (For RACK-300AxM version)PCIAGP-13S2, PCIAGP-13S3, PXAGP-12S2, PXAGP-13S, PXAGP-13S3Supports power supply:PS/2 size AT/ATX PSUOptional Sliding Rails Kit:24" or 18"Vibration:5 ~ 17Hz, 0.1" double amplitude displacement17 ~ 640Hz, 1.5G acceleration peak to peakShock:10G acceleration peak to peak (11ms)Colors:Industrial Green (PANTONE 417C) or White (PANTONE 413C)Dimensions:431(W) x 176(H) x 433(D)mm; (17" x 6.9" x 17") Net/GW (kg):11/14

4U 10-slot rackmount Black chassis with ACE-RC02 power supply case 4U height 19" Rack mounting chassisFront panel with lockable door to protect the running systemTwo reset switches for dual system applicationsAT type KBD connector on front panelDrive Bays: - 1 x 3.5" FDD - 3 x 5.25" DriveTwo 8cm cooling fans with removable filterDesigned with anti-vibration card clamp to keepsystem stableSupports backplane: BP-10S, BP-10SD, PCI-10S, IP-10S, PCIAGP-9S2,PXAGP-9SSupports 10 full size cardsBuilt-in ACE-RC02 redundant power caseSupports power supply:ACE-R20 series redundant power moduleOptional rack-mount slide : 24"Vibration:5~17Hz, 0.1" double amplitude displacement17~640Hz, 1.5G acceleration peak to peakShock: 10G acceleration peak to peak (11ms)Colors:Black (PANTONE Black C) or White (PANTONE 413C)Dimensions:431(W) x 176(H) x 511(D)mm; (17" x 6.9" x 20.1")Net/GW (kg): 17/22

4U AT MB rackmount Black chassis with ACE-RC02 4U height 19" Rack mounting chassisFront panel with lockable door to protect the running systemTwo reset switches for dual system applicationsAT type KBD connector on front panelDrive Bays: - 1 x 3.5" FDD - 3 x 5.25" DriveTwo 8cm cooling fans with removable filterDesigned with anti-vibration card clamp to keepsystem stableSupports backplane: BP-10S, BP-10SD, PCI-10S, IP-10S, PCIAGP-9S2,PXAGP-9SSupports 10 full size cardsBuilt-in ACE-RC02 redundant power caseSupports power supply:ACE-R20 series redundant power moduleOptional rack-mount slide : 24"Vibration:5~17Hz, 0.1" double amplitude displacement17~640Hz, 1.5G acceleration peak to peakShock: 10G acceleration peak to peak (11ms)Colors:Black (PANTONE Black C) or White (PANTONE 413C)Dimensions:431(W) x 176(H) x 511(D)mm; (17" x 6.9" x 20.1")Net/GW (kg): 17/22

4U 10-slot rackmount White chassis with ACE-RC02 power supply case 4U height 19" Rack mounting chassisFront panel with lockable door to protect the running systemTwo reset switches for dual system applicationsAT type KBD connector on front panelDrive Bays: - 1 x 3.5" FDD - 3 x 5.25" DriveTwo 8cm cooling fans with removable filterDesigned with anti-vibration card clamp to keepsystem stableSupports backplane: BP-10S, BP-10SD, PCI-10S, IP-10S, PCIAGP-9S2,PXAGP-9SSupports 10 full size cardsBuilt-in ACE-RC02 redundant power caseSupports power supply:ACE-R20 series redundant power moduleOptional rack-mount slide : 24"Vibration:5~17Hz, 0.1" double amplitude displacement17~640Hz, 1.5G acceleration peak to peakShock: 10G acceleration peak to peak (11ms)Colors:Black (PANTONE Black C) or White (PANTONE 413C)Dimensions:431(W) x 176(H) x 511(D)mm; (17" x 6.9" x 20.1")Net/GW (kg): 17/22
