4U AT MB rackmount White chassis with ACE-RC02 4U height 19" Rack mounting chassisFront panel with lockable door to protect the running systemTwo reset switches for dual system applicationsAT type KBD connector on front panelDrive Bays: - 1 x 3.5" FDD - 3 x 5.25" DriveTwo 8cm cooling fans with removable filterDesigned with anti-vibration card clamp to keepsystem stableSupports backplane: BP-10S, BP-10SD, PCI-10S, IP-10S, PCIAGP-9S2,PXAGP-9SSupports 10 full size cardsBuilt-in ACE-RC02 redundant power caseSupports power supply:ACE-R20 series redundant power moduleOptional rack-mount slide : 24"Vibration:5~17Hz, 0.1" double amplitude displacement17~640Hz, 1.5G acceleration peak to peakShock: 10G acceleration peak to peak (11ms)Colors:Black (PANTONE Black C) or White (PANTONE 413C)Dimensions:431(W) x 176(H) x 511(D)mm; (17" x 6.9" x 20.1")Net/GW (kg): 17/22

4U 14-slot rackmount Black chassis with ACE-C232 redundant power supply 4U height 19" Rack mounting chassisFront panel with lockable door to protect the running systemTwo reset buttons for dual system applicationsAT type KBD connector on front panel with key-lockDrive Bays:1 x 3.5" FDD, 3 x 5.25" Drive, 1 x 3.5" HDDTwo 8cm cooling fans with removable filterDesigned with an anti-vibration card clamp that keepsystem stableSupports AT/ATX form factor PC motherboardSupports backplane: PCI-14S3, PCI-14S2, PCI-14S,PX-14S5, PX-14S3,PX-14S2,IP-14S3, IP-14S, BP-14S/SD2/SD/15S, PCI-13SD, IP-13SD, IPX-13S, PCIAGP-13S2, PCIAGP-13S3, PXAGP-12S2, PXAGP-13S, PXAGP-13S3Supports power supply: PS/2 size AT/ATX SPS (ACE-93x/92x/916 series and ACE-828 series) or ACE-C232 mini redundant power supplyOptional rack-mount slide:24" or 18"Vibration:5 ~ 17Hz, 0.1" double amplitude displacement17 ~ 640Hz, 1.5G acceleration peak to peakShock:10G acceleration peak to peak (11ms)Colors:Black (PANTONE Black C) or White (PANTONE 413C)Dimensions:431(W) x 176(H) x 413(D)mm; (17" x 6.9" x 16.3")Net/GW (kg):12/15

4U 14-slot rackmount White chassis with ACE-C232 redundant power supply 4U height 19" Rack mounting chassisFront panel with lockable door to protect the running systemTwo reset buttons for dual system applicationsAT type KBD connector on front panel with key-lockDrive Bays:1 x 3.5" FDD, 3 x 5.25" Drive, 1 x 3.5" HDDTwo 8cm cooling fans with removable filterDesigned with an anti-vibration card clamp that keepsystem stableSupports AT/ATX form factor PC motherboardSupports backplane: PCI-14S3, PCI-14S2, PCI-14S,PX-14S5, PX-14S3,PX-14S2,IP-14S3, IP-14S, BP-14S/SD2/SD/15S, PCI-13SD, IP-13SD, IPX-13S, PCIAGP-13S2, PCIAGP-13S3, PXAGP-12S2, PXAGP-13S, PXAGP-13S3Supports power supply: PS/2 size AT/ATX SPS (ACE-93x/92x/916 series and ACE-828 series) or ACE-C232 mini redundant power supplyOptional rack-mount slide:24" or 18"Vibration:5 ~ 17Hz, 0.1" double amplitude displacement17 ~ 640Hz, 1.5G acceleration peak to peakShock:10G acceleration peak to peak (11ms)Colors:Black (PANTONE Black C) or White (PANTONE 413C)Dimensions:431(W) x 176(H) x 413(D)mm; (17" x 6.9" x 16.3")Net/GW (kg):12/15

4U 14-slot rackmount Black chassis with ACE-C232 Redundant power supply Construction:Heavy-duty steelDrive Bay:4 drives spaces, two 5.25", one 3.5" open and one 3.5" hiddenOptional Backplane:14-slot ISA, 14-slot PICMG (For RACK-314D, front and rearAT KBD connectors available) ATX motherboard (RACK-314DAM)System Cooling:Total three cooling fans, two 8cm fans in the front panel and one within power suplyLED Indicators and Switches:LED indicators for power on/off, HDD and KBD Links; Switches for power, reset and KBD LinkPower Supply:ATX-1125BTA-R300 300W ATX power supplyDimension in mm:177(H) X 482(W) X 450.8(D) (7" X 19" X 17.8") Weight:15.5KG (Net)Hold-down Clamp:Adjustable card retainderColor:Light gray

4U 14-slot rackmount White chassis with ACE-C232 Redundant power supply Construction:Heavy-duty steelDrive Bay:4 drives spaces, two 5.25", one 3.5" open and one 3.5" hiddenOptional Backplane:14-slot ISA, 14-slot PICMG (For RACK-314D, front and rearAT KBD connectors available) ATX motherboard (RACK-314DAM)System Cooling:Total three cooling fans, two 8cm fans in the front panel and one within power suplyLED Indicators and Switches:LED indicators for power on/off, HDD and KBD Links; Switches for power, reset and KBD LinkPower Supply:ATX-1125BTA-R300 300W ATX power supplyDimension in mm:177(H) X 482(W) X 450.8(D) (7" X 19" X 17.8") Weight:15.5KG (Net)Hold-down Clamp:Adjustable card retainderColor:Light gray

4U 14-slot rackmount White chassis with ACE-C232 redundant power supply 4U height 19" Rack mounting chassisFront panel with lockable door to protect the running systemAT type KBD connector on front panelDrive Bays :1 x 3.5" FDD, 2 x 3.5" internal and 2 x 5.25" DriveOne 12cm cooling fan with removable filterDesigned with an anti-vibration card clamp that keep the system stableSupports backplane:BP-14S, BP-14SD, PCI-13SD, PCI-14S, PCI-14S2, PCI-14S3, PX-14S5, IP-13SD, IP-14S, PCIAGP-13S2/13S3 PXAGP-12S2/13S/13S3Supports power supply: PS/2 size AT/ATX PSUVibration:5 ~ 17Hz, 0.1" double amplitude displacement17 ~ 640Hz, 1.5G acceleration peak to peakShock: 10G acceleration peak to peak (11ms)Color: White (PANTONE 413C)Dimensions: 431(W) x 177(H) x 450(D)mm; (17" x 7" x 17.7")Net/GW (kg): 15/17

4U 14-slot rackmount Black chassis with ACE-C232 redundant power supply Support 20-slot backplaneFan and Temp. MonitoringChassis intrusion switch headerSCA SCSI Subsystem4 hot-plug Ultra-160 SCA3.5" SCSI drive bays (for 1" height,80-pin SCA SCSI drives)One SAF-TE compliant SCA backplane with Qlogic GEM345 Enclosure Management Controller.SCA backplane provide power, bus termination and configuration settingsRAID Level 5 (O.S. Software RAID, with RAID control card) configuration ensures backup for SCSI drive failures.SCA backplane overheat LEDs and alarm.Failure Drive LED, Active LEDCooling Subsystem4 redundant, hot-swap system cooling fans (intake) with LED and audiblealarm to indicate fan failure.Tachometer reading and overheat speed up controlPower Supply Subsystem700W max or 350W+350W ATX redundant hot-plug power supply with PFC functionAuto-switching 100-120V/200-240V AC power supplyPower failure indicated by LED and audible alarmOptional SP350 350W ATX Power Module to upgrade as a triple redundant power supply (1050W, 350W+350W+350W).SP352-TP 350W Power Moudle output rating:12V: 25A 5V: 30A 3.3V: 28A-12V: 0.8A -5V: 0.5A 5Vsb: 2AShip with Floppy Drive, Slim CD-ROM, and Rack-mounting SlideOperating Temp.:0-50￠XCDimensions:445 x 177 x 600mm (W x H xD)

4U 14-slot rackmount White chassis with ACE-C232 redundant power supply Support 20-slot backplaneFan and Temp. MonitoringChassis intrusion switch headerSCA SCSI Subsystem4 hot-plug Ultra-160 SCA3.5" SCSI drive bays (for 1" height,80-pin SCA SCSI drives)One SAF-TE compliant SCA backplane with Qlogic GEM345 Enclosure Management Controller.SCA backplane provide power, bus termination and configuration settingsRAID Level 5 (O.S. Software RAID, with RAID control card) configuration ensures backup for SCSI drive failures.SCA backplane overheat LEDs and alarm.Failure Drive LED, Active LEDCooling Subsystem4 redundant, hot-swap system cooling fans (intake) with LED and audiblealarm to indicate fan failure.Tachometer reading and overheat speed up controlPower Supply Subsystem700W max or 350W+350W ATX redundant hot-plug power supply with PFC functionAuto-switching 100-120V/200-240V AC power supplyPower failure indicated by LED and audible alarmOptional SP350 350W ATX Power Module to upgrade as a triple redundant power supply (1050W, 350W+350W+350W).SP352-TP 350W Power Moudle output rating:12V: 25A 5V: 30A 3.3V: 28A-12V: 0.8A -5V: 0.5A 5Vsb: 2AShip with Floppy Drive, Slim CD-ROM, and Rack-mounting SlideOperating Temp.:0-50￠XCDimensions:445 x 177 x 600mm (W x H xD)
