8 Ch A/D, 3 CTR, 31 DIO 8 channel single-ended 12-bit, 20KHz A/D 3 counters 31-bits of digital I/O Software Description: Includes InstaCal ® , installation, calibration and test software. Supported by Universal Library . Also supported by most third party, high-level data acq. programs. Cables / Screw Terminal / Acces Boards: Analog: C37FF-# / CIO-MINI37 Digital: BP-37 & C37FF-# / CIO-MINI37 Expansion: C37FF# / CIO-EXP-series

8 CH A/D, 2 CH D/A, 3 CTR, 31 DIO Programmable Gains of 1,2,4,8 8 channel differential 12-bit, 20KHz A/D Dual 12-bit D/As 3 counters, 31 digital I/O Software programmable input ranges Software Description: Includes InstaCal ® , installation, calibration and test software. Supported by UniversalLibrary ® . Also supported by most third party, high-level data acq. programs. Cables / Screw Terminal / Acces. Boards: Analog: C37FF-# / CIO-MINI37 Digital: BP-40-37 & C37FF-# / CIO-MINI37 Expansion: C37FF# / CIO-EXP-series **Analog Output Specifications** Channels: 2, 12-bit resolution Output ranges: ±10V, ±5V, ±2.5V, 0-10V, 0-5V, 0-2.5V

8 CH A/D, 2 CH A/D, 3 CTR, 31 DIO Metrabyte Compatible Ranges 8 channel differential 12-bit, 20KHz A/D Dual 12-bit D/As 3 counters, 31 digital I/O Software programmable input ranges Software Description: Includes InstaCal ® , installation, calibration and test software. Supported by UniversalLibrary ® . Also supported by most third party, high-level data acq. programs. Cables / Screw Terminal / Acces. Boards: Analog: C37FF-# / CIO-MINI37 Digital: BP-40-37 & C37FF-# / CIO-MINI37 Expansion: C37FF# / CIO-EXP-series **Analog Output Specifications** Channels: 2, 12-bit resolution Output ranges: ±10V, ±5V, ±2.5V, 0-10V, 0-5V, 0-2.5V

8 Ch A/D, 3 CTR, 7 DIO Programmable Gains of 1,10,100,1000 8 channel differential 12-bit, 20KHz A/D 3 counters, 7 digital I/O Software programmable input ranges Software Description: Includes InstaCal ® , installation, calibration and test software. Supported by UniversalLibrary ® . Also supported by most third party, high-level data acq. programs. Cables / Screw Terminal / Acces. Boards: Analog: C37FF-# / CIO-MINI37 Expansion: C37FF# / CIO-EXP-series

8 Ch A/D, 3 CTR, 7 DIO Programmable Gains of 1, 2, 4 & 8 8 channel differential 12-bit, 20KHz A/D 3 counters, 7 digital I/O Software programmable input ranges Software Description: Includes InstaCal ® , installation, calibration and test software. Supported by UniversalLibrary ® . Also supported by most third party, high-level data acq. programs. Cables / Screw Terminal / Acces. Boards: Analog: C37FF-# / CIO-MINI37 Expansion: C37FF# / CIO-EXP-series

8 Ch A/D, 3 CTR, 7 DIO Metrabyte Compatible Gains 8 channel differential 12-bit, 20KHz A/D 3 counters, 7 digital I/O Software programmable input ranges Software Description: Includes InstaCal ® , installation, calibration and test software. Supported by UniversalLibrary ® . Also supported by most third party, high-level data acq. programs. Cables / Screw Terminal / Acces. Boards: Analog: C37FF-# / CIO-MINI37 Expansion: C37FF# / CIO-EXP-series

16 Channel, 12 Bit A/D with Burst Mode & Programmable Gains of 1,10,100,1000 8 ch diff. / 16 single-ended 12-bit A/D Burst-mode A/D timing 512 sample FIFO 3 counters 8-bits digital I/O Digital Input/Output: Digital I/O specs: TTL series Counters: 3 CMOS, 8254 series Software Description: Includes InstaCal ® , installation, calibration and test software. Supported by UniversalLibrary ® . Also supported by most third party, high-level data acq. programs. Cables / Screw Terminal Boards: Analog: C37FF-# / CIO-MINI37 Simultaneous S&H: C37FF-# / CIO-SSH-16

16 Ch A/D @ 330KHz, 3 CTR, DT CONNECT INTERFACE 8 ch diff. / 16 single-ended 12-bit A/D (1 part in 4096) 330 Khz sample rate 1024 sample FIFO DT-Connect compatible MEGA-FIFO compatible CIO-SSH-16 compatible Simultaneous Sample & Hold w/CIO-SSH-16 Channels up to 16 Aperture time 175 nSec (avg) Aperture uncertainty ± 25 nSec Software Description: Includes InstaCal ® , installation, calibration and test software. Supported by UniversalLibrary ® . Also supported by most third party, high-level data acq. programs. Cables/Screw Terminal Boards: **Standard I/O Connection: ** Mating cable: C37FF-# series Screw terminal board: CIO-MINI37 **For Simultaneous Sample & Hold Operation** Cable: C37FF-# series SSH board CIO-SSH-16
