PC Based Instruments | Expansion Module
WBK13A
8-Channel Programmable Low-Pass Filter Card with Simultaneous Sample and Hold IOtech's WBK13A is an 8-channel programmable low-pass filter card with simultaneous sample and hold, for use with WaveBook data acquisition systems. This card, which installs* directly into any WaveBook or WBK10A expansion module, provides programmable low-pass filtering over all channels. 8-channel programmable low-pass anti-aliasing filtering Software-programmable 8-pole filters, configurable as elliptic or linear phase Programmable-cutoff frequencies from 400 Hz to 100 kHz 2 cutoff frequencies per card, configurable in two 4-channel banks Full-scale programmable input ranges; Unipolar: +100 mV to +10V; Bipolar: ±50 mV to ±10V Provides 8 input channels with simultaneous sampling Samples all system channels within 100 ns of one another
$7499.00
WBK15
8-Channel Multifunction Isolated Signal Conditioning Module IOtech's WBK15 8-channel multifunction isolated signal conditioning module allows the accommodation of any combination of up to eight optional 5B input signal conditioning modules. Each user-installable signal conditioning module offers 1500V isolation from the system and from other channels. The WBK15 is available with a wide variety of modules that accommodate an array of signals – from low-level thermocouple signals to strain gage signals.
$3432.00
WBK17
8-Channel Counter/Encoder/High-Voltage Module The WBK17 is an 8-channel multifunction counter/encoder module for Wavebook and StrainBook data acquisition systems. Each counter channel can read inputs directly from encoders, pulse generators, limit switches, proximity switches, or magnetic pickups. All channels are also capable of measuring analog inputs, which are digitized by the Wavebook or StrainBook at up to 1 MHz.
$5783.00
