Detailed features:
High performance, USB powered modules for sound & vibration analysis
The DT9837 series high-accuracy dynamic signal acquisition modules are ideal for portable noise, vibration and acoustic measurements with four, 24-bit, A/D converters. These rugged, compact modules are USB powered.
DT9837C-BNC has 1Hz high-pass filter on analog input subsystem.
Also,DT9837C-BNC has RJ45 synchronization connector to synchronize acquisition on up to four modules.
Analog output subsystem (DT9837C-BNC)
*One 24-bit D/A converter
*Single value, waveform and continuous streaming output
*programmable output rate from 10 kS/s to 96 kS/s
*Output range of +/- 3V
*+/- 2 mA output current
*Software-programmable trigger type (software trigger, external digital trigger, or analog threshold trigger) to start the analog output operation
*View all specifications for DT9837 series click here
*View manual for DT9837 series click here
High performance, USB powered modules for sound & vibration analysis
The DT9837 series high-accuracy dynamic signal acquisition modules are ideal for portable noise, vibration and acoustic measurements with four, 24-bit, A/D converters. These rugged, compact modules are USB powered.
DT9837C-BNC has 1Hz high-pass filter on analog input subsystem.
Also,DT9837C-BNC has RJ45 synchronization connector to synchronize acquisition on up to four modules.
Analog output subsystem (DT9837C-BNC)
*One 24-bit D/A converter
*Single value, waveform and continuous streaming output
*programmable output rate from 10 kS/s to 96 kS/s
*Output range of +/- 3V
*+/- 2 mA output current
*Software-programmable trigger type (software trigger, external digital trigger, or analog threshold trigger) to start the analog output operation
*View all specifications for DT9837 series click here
*View manual for DT9837 series click here
Specifications:
FOR MODEL **** DT9837C-BNC****
# of Analog Inputs
4 single-ended, simultaneous channels
Resolution
24-bit
Max sample rate/ch analog input
105.4 kS/s (analog input)
Threshold Trigger
Programmable
high-pass filter
1 Hz
Analog Output
1 channel, Waveform streaming
Max sample rate analog output
96 kS/s
