Industrial Automation | Programmable Controllers
I-8065
FEATURES: 8-channel SSR-AC Output Module SPECIFICATIONS: Parallel I/O Module Insulation resistance: Digital Output Channels: 8 Min. 1,000 M£[, at 500Vdc Form A x 8 channels Life: long life, maintenance free Contact Rating AC: 24 to 265Vrms @1.0Arms LED indicator for each digital output 7000 command compatible Max. load current: 1.0 Arms support dual watchdog function Min. load current: 10 mArms support power-up value for each digital output Max. off-state leakage current: 0.75mA ( at 100 Vrms 60Hz ), 1.5mA ( at 200 Vrms 60 Hz ) support safe value for each digital output Power Consumption: 0.8W 1 cycle surge current: 50A ( 60Hz) Max. off-state voltage drop: 2Vrms Max. operate time: 1 ms Max. release time: 1/2 cycle + 1 ms
$614.00
I-8065G
FEATURES: 8-channel SSR-AC Output Module SPECIFICATIONS: Parallel I/O Module Insulation resistance: Digital Output Channels: 8 Min. 1,000 M£[, at 500Vdc Form A x 8 channels Life: long life, maintenance free Contact Rating AC: 24 to 265Vrms @1.0Arms LED indicator for each digital output 7000 command compatible Max. load current: 1.0 Arms support dual watchdog function Min. load current: 10 mArms support power-up value for each digital output Max. off-state leakage current: 0.75mA ( at 100 Vrms 60Hz ), 1.5mA ( at 200 Vrms 60 Hz ) support safe value for each digital output Power Consumption: 0.8W 1 cycle surge current: 50A ( 60Hz) Max. off-state voltage drop: 2Vrms Max. operate time: 1 ms Max. release time: 1/2 cycle + 1 ms
$579.00
I-8066
FEATURES: 8-channel SSR-DC Output Module SPECIFICATIONS: Parallel I/O Module Insulation resistance: Min. 1,000 M£[, at 500Vdc Digital Output Channels: 8 Life: long life, maintenance free Form A x 8 channels LED indicator for eachl digital output Contact Rating DC: -30Vdc @ 1A 7000 command compatible support dual watchdog function Max. load current: 1.0 A support power-up value for each digital output Min. load current: 1 mA support safe value for each digital output Max. off-state leakage current: 0.1 mA ( at 30 Vdc ) support safe value for each digital output 1 cycle surge current: 3A ( 10ms ) Power Consumption: 0.8W Max. off-state voltage drop: 1.2V Max. operate time: 1 ms Max. release time: 1 ms
$591.00
I-8066G
8-channel SSR-DC Output Module Parallel I/O Module Insulation resistance: Min. 1,000 M£[, at 500Vdc Digital Output Channels: 8 Life: long life, maintenance free Form A x 8 channels LED indicator for eachl digital output Contact Rating DC: -30Vdc @ 1A 7000 command compatible support dual watchdog function Max. load current: 1.0 A support power-up value for each digital output Min. load current: 1 mA support safe value for each digital output Max. off-state leakage current: 0.1 mA ( at 30 Vdc ) support safe value for each digital output 1 cycle surge current: 3A ( 10ms ) Power Consumption: 0.8W Max. off-state voltage drop: 1.2V Max. operate time: 1 ms Max. release time: 1 ms
$566.00
I-8068
FEATURES: 8-channel Relay Output Module SPECIFICATIONS: Parallel I/O Module Digital Output Channels: 8 Form C x 4 Form A x 4 Contact Rating AC: 120V @0.5A DC:30V @ 1A Insulation resistance: 1000MW min at 500Vdc LED indicator for each digital output Power Consumption: 0.8W
$262.00
I-8068G
FEATURES: 8-channel Relay Output Module SPECIFICATIONS: Parallel I/O Module Digital Output Channels: 8 Form C x 4 Form A x 4 Contact Rating AC: 120V @0.5A DC:30V @ 1A Insulation resistance: 1000MW min at 500Vdc LED indicator for each digital output Power Consumption: 0.8W
$260.00
I-8069
FEATURES: 8-channel PhotoMOS Relay Output Module SPECIFICATIONS: Parallel I/O Module Channels: 8 (Form A) Continuous load current:0.13A (peak AC) Peak load current: 0.4A Output Power dissipation : 0.5W Output Off state leakage current : 1uA Output On resistance : 23Ohm Load voltage : 350V(peak AC) Turn On time : 0.7ms (typical) Turn Off time : 0.05ms (typical) Input / Output Isolation : 5,000Vac optical isolation Power consumption: 0.5W
$304.00
I-8069G
FEATURES: 8-channel PhotoMOS Relay Output Module SPECIFICATIONS: Parallel I/O Module Channels: 8 (Form A) Continuous load current:0.13A (peak AC) Peak load current: 0.4A Output Power dissipation : 0.5W Output Off state leakage current : 1uA Output On resistance : 23Ohm Load voltage : 350V(peak AC) Turn On time : 0.7ms (typical) Turn Off time : 0.05ms (typical) Input / Output Isolation : 5,000Vac optical isolation Power consumption: 0.5W
$289.00
