Industrial Automation | i-7000 modules & cards | I-7041
Detailed features:
Isolated Digital Input Module
Digital Input
Communication Interface
Power Supply
Isolated Digital Input Module
Digital Input
- Channels: 14
- Digital input status:
Isolated channel with common power - Digital input level:
Logic level 0:+1V max.
Logic level 1:+4V to +30V
Isolation voltage: 3750V rms
input impedance:3KOhm, 0.5W - D/I can be used as counter channels: 14
Input Frequency: 100Hz
16-bit: 0~6,5535
Communication Interface
- RS-485
Power Supply
- Input Power: 10~30Vdc
- Consumption :
0.2W for I-7041
0.9W for I-7041D
Specifications:
# Digital Input
14
Logic level 0
+1V max.
Logic level 1
+4V to +30V
Isolation voltage
3750V rms
input impedance
3KOhm, 0.5W
Input Frequency
100Hz
Consumption
0.2W for I-7041
