Acquisition & Control on PC | Signal Conditioners
ISO-5B31-01
+/- 1V Input, +/-5V Output Analog Isolation Module Features:1500 Vrms Isolation High Common Mode Rejection Low CostSpecifications:Input Range: ± 1 V Full Scale Output Range: ± 5 V Nonlinearity: ± 0.02% Input Offset: ± 20μV°C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B31-02
+/- 5V Input, +/- 5V Output Analog Isolation Module Features:1500 Vrms Isolation High Common Mode Rejection Low CostSpecifications:Input Range: ± 5 V Full Scale Output Range: ± 5 V Nonlinearity: ± 0.02% Input Offset: ± 20μV°C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B31-03
+/- 10V Input, +/- 5V Output Analog Isolation Module Features:1500 Vrms Isolation High Common Mode Rejection Low CostSpecifications:Input Range: ± 10 V Full Scale Output Range: ± 5 V Nonlinearity: ± 0.02% Input Offset: ± 20μV°C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B31-04
+/- 1V Input, 0 To 5V Output Analog Isolation Module Features:1500 Vrms Isolation High Common Mode Rejection Low CostSpecifications:Input Range: ± 1V Full Scale Output Range: 0-5 V Nonlinearity: ± 0.02% Input Offset: ± 20μV°C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B31-05
+/- 5V Input, 0 To 5V Output Analog Isolation Module Features:1500 Vrms Isolation High Common Mode Rejection Low CostSpecifications:Input Range: ± 5V Full Scale Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 20μV°C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B31-06
+/- 10V Input, 0 To 5V Output Analog Isolation Module Features:1500 Vrms Isolation High Common Mode Rejection Low CostSpecifications:Input Range: ± 10V Full Scale Output Range: 0-5 V Nonlinearity: ± 0.02% Input Offset: ± 20μV°C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B31-07
+/- 20V Input, -/+ 5V Output Features:1500 Vrms Isolation High Common Mode Rejection Low CostSpecifications:Input Range: ± 20 V Full Scale Output Range: ± 5 V Nonlinearity: ± 0.02% Input Offset: ± 20μV°C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B31-08
+/- 20V Input, 0V to +5V Output Features:1500 Vrms Isolation High Common Mode Rejection Low CostFeatures:1500 Vrms Isolation High Common Mode Rejection Low CostSpecifications:Input Range: ± 20 V Full Scale Output Range: 0-5 Nonlinearity: ± 0.02% Input Offset: ± 20μV°C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
