Acquisition & Control on PC | Signal Conditioners
ISO-5B32-01
4-20 mA Input, 0 To 5V Output Analog Isolation Module Features:4-20 mA input 1500 Vrms Isolation Low CostSpecifications:Input Range: 4-20mA Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 50nA°C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B32-02
0-20 mA Input, 0 To 5V Output Analog Isolation Module Features:4-20 mA input 1500 Vrms Isolation Low CostSpecifications:Input Range: 0-20mA Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 50nA°C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
