Industrial Automation | Signal Conditioners
ISO-5B47-B-11
Type B, +500 to +1800 deg C Input, 0 to +5V Output Features:Linearized Thermocouple Inputs CJC Circuitry 1500 Vrms Low CostSpecifications:Input Range: +500C to +1800C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB NMR at 50 or 60 Hz: 90dBMounting Options:ISO-RACK8 and ISO-RACK16
$353.00
ISO-5B47-J-01
Analog Isolation Module J Thermocouple +32 deg C to+760 deg C Input, 0-5V Output Features:Linearized Thermocouple Inputs CJC Circuitry 1500 Vrms Low CostSpecifications:Input Range: +500C to +1800C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB NMR at 50 or 60 Hz: 90dBMounting Options:ISO-RACK8 and ISO-RACK16
$353.00
ISO-5B47-J-02
Analog Isolation Module J Thermocouple -100 deg C to +300 deg C Input, 0-5V Output Features:Linearized Thermocouple Inputs CJC Circuitry 1500 Vrms Low CostSpecifications:Input Range: -100C to +300C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB NMR at 50 or 60 Hz: 90dBMounting Options:ISO-RACK8 and ISO-RACK16
$353.00
ISO-5B47-J-03
Analog Isolation Module J Thermocouple +0 deg C TO +500 deg C INPUT, 0-5V OUTPUT Features:Linearized Thermocouple Inputs CJC Circuitry 1500 Vrms Low CostSpecifications:Input Range: 0C to +500C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB NMR at 50 or 60 Hz: 90dBMounting Options:ISO-RACK8 and ISO-RACK16
$353.00
ISO-5B47-K-04
Analog Isolation Module K Thermocouple 0 deg C to 1000 deg C Input, 0 to 5 Volt Output Features:Linearized Thermocouple Inputs CJC Circuitry 1500 Vrms Low CostSpecifications:Input Range: 0C to +1000C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB NMR at 50 or 60 Hz: 90dBMounting Options:ISO-RACK8 and ISO-RACK16
$353.00
ISO-5B47-K-05
Analog Isolation Module K Thermocouple +0 deg C TO +500 deg C INPUT, 0-5V OUTPUT Features:Linearized Thermocouple Inputs CJC Circuitry 1500 Vrms Low CostSpecifications:Input Range: 0C to +1000C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB NMR at 50 or 60 Hz: 90dBMounting Options:ISO-RACK8 and ISO-RACK16
$353.00
ISO-5B47-K-13
Analog Isolation Module K Thermocouple -100 deg C to +1350 deg C Input, 0V to +5V Output Features:Linearized Thermocouple Inputs CJC Circuitry 1500 Vrms Low Cost Specifications: Input Range: -100°C to +1350°C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV°C Output Offset: ± 20μV°C Output Resistance: 50 Ohms Bandwidth: -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 VrmsCMR at 50-60 Hz: 160 dB NMR: 95dB at 60 Hz; 90dB at 50 HzMounting Options: ISO-RACK8 and ISO-RACK16
$353.00
