Industrial Automation | Signal Conditioners
ISO-5B47-K-14
Type K, 0 to +1200 deg C in, 0 to +5V out Features:Linearized Thermocouple Inputs CJC Circuitry 1500 Vrms Low CostSpecifications:Input Range: 0C to +1200C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB NMR at 50 or 60 Hz: 90dBMounting Options:ISO-RACK8 and ISO-RACK16
$353.00
ISO-5B47-R-09
Type R, +500 to +1750 deg C in, 0 to +5V out Features:Linearized Thermocouple Inputs CJC Circuitry 1500 Vrms Low CostSpecifications:Input Range: +500C to +1750C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB NMR at 50 or 60 Hz: 90dBMounting Options:ISO-RACK8 and ISO-RACK16
$353.00
ISO-5B47-S-10
Analog Isolation Module S Thermocouple +500 deg C TO +1750 deg C INPUT, 0-5V OUTPUT Features:Linearized Thermocouple Inputs CJC Circuitry 1500 Vrms Low CostSpecifications:Input Range: +500C to +1750C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB NMR at 50 or 60 Hz: 90dBMounting Options:ISO-RACK8 and ISO-RACK16
$353.00
ISO-5B47-T-06
Type T, -100 to +400 deg C in,0 to +5 out Features:Linearized Thermocouple Inputs CJC Circuitry 1500 Vrms Low CostSpecifications:Input Range: -100C to +400C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB NMR at 50 or 60 Hz: 90dBMounting Options:ISO-RACK8 and ISO-RACK16
$353.00
ISO-5B47-T07
Type T, 0 to 200 deg C in, 0 to 5 V out Features:Linearized Thermocouple Inputs CJC Circuitry 1500 Vrms Low CostSpecifications:Input Range: 0C to +200C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB NMR at 50 or 60 Hz: 90dBMounting Options:ISO-RACK8 and ISO-RACK16
$353.00
