ISO-5B40-04
+/- 10mV In, 0 to +5V Out, Wide Bandwidth Features:Wide Bandwith (10 KHz) 1500 Vrms Isolation Low CostSpecifications:Input Range: ± 10mV Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 40μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 10 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B40-05
+/- 5V in, 0 to 5V out Wide Bandwidth Analog Isolation Module Features:Wide Bandwith (10 KHz) 1500 Vrms Isolation Low CostSpecifications:Input Range: ± 50mV Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 40μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 10 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B40-06
+/- 10V in, 0 to 5V out Wide Bandwidth Analog Isolation Module Features:Wide Bandwith (10 KHz) 1500 Vrms Isolation Low CostSpecifications:Input Range: ± 100mV Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 40μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 10 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B41-01
Isolation module - wide band +/-1V input, +/-5V output Features:Wide Bandwith (10 KHz) 1500 Vrms Isolation Low CostSpecifications:Input Range: ± 1V Output Range: ± 5V Nonlinearity: ± 0.02% Input Offset: ± 20μV/ deg C Output Offset: ± 40μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 10 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB
$249.00
ISO-5B41-02
Isolation module - wide band +/-5V input, +/-5V output Features:Wide Bandwith (10 KHz) 1500 Vrms Isolation Low CostSpecifications:Input Range: ± 5V Output Range: ± 5V Nonlinearity: ± 0.02% Input Offset: ± 20μV/ deg C Output Offset: ± 40μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 10 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB
$249.00
ISO-5B41-03
Isolation module - wide band +/-10V input, +/-5V output Features:Wide Bandwith (10 KHz) 1500 Vrms Isolation Low CostSpecifications:Input Range: ± 10V Output Range: ± 5V Nonlinearity: ± 0.02% Input Offset: ± 20μV/ deg C Output Offset: ± 40μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 10 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB
$249.00
ISO-5B41-04
+/- 1V In, 0-5V Out Analog Isolation Module Features:Wide Bandwith (10 KHz) 1500 Vrms Isolation Low CostSpecifications:Input Range: ± 1V Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 20μV/ deg C Output Offset: ± 40μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 10 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB
$249.00
ISO-5B41-05
+/- 5 V in, 0 to 5 V out - 10 KHZ Analog Isolation Module Features:Wide Bandwith (10 KHz) 1500 Vrms Isolation Low CostSpecifications:Input Range: ± 5V Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 20μV/ deg C Output Offset: ± 40μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 10 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dB
$249.00
