T- Type T-C, -100 to +400 Deg C Input, 0-5V Output, Non-Linearized Isolation Module Features:T - Type Thermocouple input CJC circuitry 1500 Vrms IsolationSpecifications:Input Range: 0C to +900C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 0.02dC/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16

100 to 10K OHM In, -5V to +5V Out Features:Strain Gage Input 1500 Vrms Low CostSpecifications:Full, (3.333V @ 3mV/V) 100 to 10KOhmMounting Options:ISO-RACK8 and ISO-RACK16

Isolation module 10V Excitation Strain Gauge - FULL BRDG Features:Strain Gage Input 1500 Vrms Low CostSpecifications:Full, (10.0V @ 3mV/V) 300 to 10KOhmMounting Options:ISO-RACK8 and ISO-RACK16

Half Bridge Strain Gage input module 100 to 10k ohms in, -5 to +5 out Features:Strain Gage Input 1500 Vrms Low CostSpecifications:Full, (3.333V @ 3mV/V) 100 to 10KOhmMounting Options:ISO-RACK8 and ISO-RACK16 Acquisition and control PC

Isolation module 10V Excitation Strain Gauge - HALF BRDG Features:Strain Gage Input 1500 Vrms Low CostSpecifications:Half, (10.0V @ 3mV/V) 300 to 10KOhmMounting Options:ISO-RACK8 and ISO-RACK16

Strain Guage input module. 10 V @ 2mV/V 300 to 10K in, -5 to +5 out Features:Strain Gage Input 1500 Vrms Low CostSpecifications:Full, (10.0V @ 2mV/V) 300 to 10KOhmMounting Options:ISO-RACK8 and ISO-RACK16

100 to 10K OHM In, -5 to +5V Out 3.333V at 10mV/V Sensitivity Features:Strain Gage Input 1500 Vrms Low CostSpecifications:Full, (3.333V @ 10mV/V) 100 to 10KOhmMounting Options:ISO-RACK8 and ISO-RACK16

300 Ohm to 10K Ohm In, -5V to +5V Out
