Acquisition & Control on PC | Signal Conditioners
ISO-5B39-01
0 - 5 Volt in, 4 - 20 mA out analog isolation module Features:Current Output Module 1500 Vrms Isolation Low CostSpecifications:TBDMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B39-02
Current Output Isolation Module +/- 5V Input, 4-20mA Output Features:Current Output Module 1500 Vrms Isolation Low CostSpecifications:TBDMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B39-03
0 to 5 volt in, 0 to 20 mA out Analog isolation module Features:Current Output Module 1500 Vrms Isolation Low CostSpecifications:TBDMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B39-04
+/- 5 Volt in, 0 - 20 mA out analog isolation module Features:Current Output Module 1500 Vrms Isolation Low CostSpecifications:TBDMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B40-01
Isolated Wide Band Voltage Input Module +/- 10MV In, +/- 5 Volts Out Features:Wide Bandwith (10 KHz) 1500 Vrms Isolation Low CostSpecifications:Input Range: ± 10mV Output Range: ± 5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 40μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 10 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B40-02
Isolated Wide Band Voltage Input Module +/- 50 MV In, +/- 5 Volts Out Features:Wide Bandwith (10 KHz) 1500 Vrms Isolation Low CostSpecifications:Input Range: ± 50mV Output Range: ± 5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 40μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 10 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B40-03
Isolation module +/-100mV input, +/-5V output Features:Wide Bandwith (10 KHz) 1500 Vrms Isolation Low CostSpecifications:Input Range: ± 100mV Output Range: ± 5V Nonlinearity: ± 0.02% Input Offset: ± 1μV/ deg C Output Offset: ± 40μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 10 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 100 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
