ISO-5B37-B
B- Type T-C, 0 To 1800 Deg C Input, 0 To 5V Output, Non-Linearized Analog Isolation Module Features: B- Type Thermocouple input CJC circury 1500 Vrms Isolation Specifications:Input Range: 0C to +1800C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 0.02dC/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B37-C
C- Type T-C, +350 to +1300 Deg C Input, 0V to + 5V Output, Non-Linearized Analog Isolation Module Features:C- Type Thermocouple input CJC circuitry 1500 Vrms Isolation Specifications:Input Range: +350C to +1300C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 0.02dC/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B37-E
C- Type T-C, +350 to +1300 Deg C Input, 0V to + 5V Output, Non-Linearized Analog Isolation Module Features:E- Type thermocouple input CJC circuitry 1500 Vrms IsolationSpecifications:Input Range: 0C to +900C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 0.02dC/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B37-J
J- Type T-C, -100 to 760 Deg C Input, 0 to 5V Output, Non-Linearized Analog Isolation Module Features:J- Type Thermocouple input CJC circuitry 1500 Vrms IsolationSpecifications:Input Range: -100C to +760C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 0.02dC/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B37-K
K Type T-C, -100 to 760 Deg C Input, 0 to 5V Output, Non-Linearized Analog Isolation Module Features:K- Type Thermocouple input CJC circuitry 1500 Vrms IsolationSpecifications:Input Range: -100C to +760C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 0.02dC/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B37-R
R- Type T-C, 0 to 1750 Deg C Input, 0 to 5 V Output, Non-Linearized Analog Isolation Module Features:R- Type Thermocouple input CJC circuitry 1500 Vrms IsolationSpecifications:Input Range: 0C to +1750C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 0.02dC/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
ISO-5B37-S
S- Type T-C, 0 to 1750 Deg C Input, 0 to 5V Output, Non-Linearized Thermocouple Isolation Module Features:S- Type Thermocouple input CJC circuitry 1500 Vrms IsolationSpecifications:Input Range: 0C to 1750C Output Range: 0-5V Nonlinearity: ± 0.02% Input Offset: ± 0.02dC/ deg C Output Offset: ± 20μV°C Output Resistance: 50 Ohm Bandwidth, -3dB: 4 Hz Output Protection: Continuous Short to Ground Isolation: 1500 Vrms CMR at 50-60 Hz: 160 dB NMR at 50-60 Hz: 90 dBMounting Options:ISO-RACK8 and ISO-RACK16
$249.00
