Industrial Automation | i-7000 modules & cards
I-7033
3-channel RTD Input Module Analog Input Photo-isolation: 3750 Vrms Channels: 3 Input Type: Pt , Ni Sampling rate: 15/12.5 samples/second while filter at 60/50Hz Bandwidth: 15.7 Hz Wire connection: 2/3/4 wire Accuracy: !O 0.1% Zero drift : !O 0.5uV/￠J Span drift: !O25uV/￠J CMR @ 50/60 Hz: 150 dB min NMR @ 50/60 Hz: 100 dB min Display LED 4 1/2 digits (for I-7033D only) Communication Interface RS-485 Power Supply Input Voltage Range: +10 to +30 Vdc Consumption: 1.0W for I-7033 1.6W for I-7033D
$478.00
I-7033D
3-channel RTD Input Module with LED Display Analog Input Photo-isolation: 3750 Vrms Channels: 3 Input Type: Pt , Ni Sampling rate: 15/12.5 samples/second while filter at 60/50Hz Bandwidth: 15.7 Hz Wire connection: 2/3/4 wire Accuracy: !O 0.1% Zero drift : !O 0.5uV/￠J Span drift: !O25uV/￠J CMR @ 50/60 Hz: 150 dB min NMR @ 50/60 Hz: 100 dB min Display LED 4 1/2 digits (for I-7033D only) Communication Interface RS-485 Power Supply Input Voltage Range: +10 to +30 Vdc Consumption: 1.0W for I-7033 1.6W for I-7033D
$579.00
I-7041
Isolated Digital Input Module Digital Input Channels: 14 Digital input status: Isolated channel with common power Digital input level: Logic level 0:+1V max. Logic level 1:+4V to +30V Isolation voltage: 3750V rms input impedance:3KOhm, 0.5W D/I can be used as counter channels: 14 Input Frequency: 100Hz 16-bit: 0~6,5535 Communication Interface RS-485 Power Supply Input Power: 10~30Vdc Consumption : 0.2W for I-7041 0.9W for I-7041D
$215.00
I-7041D
Isolated Digital Input Module with LED Display Digital Input Channels: 14 LED indicated Digital input status: Isolated channel with common power Digital input level: Logic level 0:+1V max. Logic level 1:+4V to +30V Isolation voltage: 3750V rms input impedance:3KOhm, 0.5W D/I can be used as counter channels: 14 Input Frequency: 100Hz 16-bit: 0~6,5535 Communication Interface RS-485 Power Supply Input Power: 10~30Vdc Consumption : 0.2W for I-7041 0.9W for I-7041D
$231.00
I-7042
Isolated O.C. Output Module Digital Input Channels: 13 Isolation Digital Output status Open collector to 30V max. Output current: 100mA per channel Isolation Voltage: 3750V Direct drive power relay module Communication Interface RS-485 Power Supply Input Power: 10~30Vdc Consumption : 1.0W for I-7042 1.7W for I-7042D
$215.00
I-7042D
Isolated O.C. Output Module with LED Display Digital Input Channels: 13 LED indicated Isolation Digital Output status Open collector to 30V max. Output current: 100mA per channel Isolation Voltage: 3750V Direct drive power relay module Communication Interface RS-485 Power Supply Input Power: 10~30Vdc Consumption : 1.0W for I-7042 1.7W for I-7042D
$231.00
I-7043
16-Channel O.C. Output Module Digital Input Channels: 16 Open collector to 30V max. Output current: 100mA per channel. Direct drive power relay module Communication Interface RS-485 Power Supply Input Power: 10~30Vdc Consumption : 10.4W for I-7043 1.1W for I-7043D
$215.00
I-7043D
Isolated O.C. Output Module with LED Display Digital Input Channels: 16 LED indicated Digital output status Open collector to 30V max. Output current: 100mA per channel. Direct drive power relay module Communication Interface RS-485 Power Supply Input Power: 10~30Vdc Consumption : 10.4W for I-7043 1.1W for I-7043D
$231.00
